RBmax10L-F LiFePO4 Battery

Meet the safe, efficient, and reliable power storage solutions - the ROYPOW 10 kWh LiFePO4 battery. Whether for powering a remote cabin, backup systems, or an off-grid home, ROYPOW battery solutions, featuring cutting-edge LiFePO4 technologies, long design life, flexible capacity expansion, and low maintenance, are the ideal choices for sustainable and uninterrupted home energy storage.

  • Product Description
  • Product Specifications
  • PDF Download
10 kWh

10 kWh

LiFePO4 Battery
  • background
    20 Years of Design Life
  • background
    8 Units Flexible Capacity Expansion
  • background
    >6,000 Times Cycle Life
  • background
    10 Years Warranty
  • Easy Installation

    Easy Installation

    Wall Mounted
  • Intelligent BMS

    Intelligent BMS

    Multiple Safe Protections
  • High Compatibility

    High Compatibility

    Compatible with Many Brands of Inverters
  • 10 kWh

    10 kWh

    LiFePO4 Battery
    Model RBmax10L-F
      • Electric Data

      Nominal Energy (kWh) 9.84kWh
      Usable Energy (kWh) 9.05kWh
      Cell Type LFP (LiFePO4)
      Nominal Voltage (V) 48V
      Rated capacity(Ah) 205Ah
      Combination method 15S1P
      Operating Voltage Range (V) 40.5~54
      Max. Continuous Charge Current(A) 200
      Max. Continuous Discharge Current(A) 200
      • General Data

      Weight
      90 Kg / 198.42 lbs.
      Dimensions (W × D × H) (mm) 500*180*800
      Operating Temperature (°C) 0~ 55℃ (Charge), -20~55℃ (Discharge)
      Storage Temperature (°C)
      Delivery SOC State (20~40%)
      >1 Month: 0~35℃; ≤1 Month: -20~45℃
      Relative Humidity ≤ 95%
      Max. Altitude (m) 4000 (>2000m Derating)
      Protection Degree IP 20
      Installation Location Ground-Mounted; Wall-Mounted
      Communication CAN, RS485
      • Certification

      EMC CE
      Transportation UN38.3
      • Warranty

      Warranty (Years) 5 Years




    • File Name
    • File Type
    • Language
    • pdf_ico

      ROYPOW-Off-Grid-Energy-Storage-System-Brochure-Ukrainian -Ver.-August-26-2024

    • Ukrainian
    • down_ico
    • pdf_ico

      ROYPOW-Off-Grid-Energy-Storage-System-Brochure-Burmese-Ver.-August-26-2024

    • Burmese
    • down_ico
    • pdf_ico

      ROYPOW Off-Grid Energy Storage System Brochure (Euro-Standard) - Ver. October 28, 2024

    • EN
    • down_ico
    RBmax10L-F LiFePO4 Battery-1
    RBmax10L-F LiFePO4 Battery-2
    RBmax10L-F LiFePO4 Battery-3
    RBmax10L-F LiFePO4 Battery-4
    built-in BMS

    FAQ

    • 1. Can off-grid inverter work without battery?

      +

      Yes, it’s possible to use a solar panel and inverter without a battery. In this setup, the solar panel converts sunlight into DC electricity, which the inverter then converts into AC electricity for immediate use or to feed into the grid.

      However, without a battery, you can’t store excess electricity. This means that when sunlight is insufficient or absent, the system won’t provide power, and direct use of the system may lead to power interruptions if sunlight fluctuates.

    • 2. How long do off-grid batteries last?

      +

      Typically, Most solar batteries on the market today last between 5 and 15 years.

      ROYPOW off-grid batteries support up to 20 years of design life and over 6,000 times of cycle life. Treating the battery right with proper care and maintenance will ensure a battery will reach its optimal lifespan or even further.

    • 3. How many batteries do I need for off-grid solar?

      +

      Before you can determine how many solar batteries are required to power your home, you need to consider a few key factors:

      Time (hours): The number of hours you plan to rely on stored energy per day.

      Electricity demand (kW): The total power consumption of all the appliances and systems you intend to run during those hours.

      Battery capacity (kWh): Typically, a standard solar battery has a capacity of about 10 kilowatt-hours (kWh).

      With these figures in hand, calculate the total kilowatt-hour (kWh) capacity needed by multiplying the electricity demand of your appliances by the hours they’ll be in use. This will give you the required storage capacity. Then, assess how many batteries are needed to meet this requirement based on their usable capacity.

    • 4. What is the best battery for off-grid solar system?

      +

      The best batteries for off-grid solar systems are lithium-ion and LiFePO4. Both outperform other types in off-grid applications, offering faster charging, superior performance, longer lifespan, zero maintenance, higher safety, and lower environmental impact.
